Garlock gaskets specifications
Material type: Flexible graphite gasket with stainless steel insert
Operating pressure: suitable for high-pressure flange systems
Temperature range: −200 °C to +450 °C (up to +550 °C in non-oxidizing environments)
Creep resistance: excellent
Sealing performance: highly reliable under fluctuating loads
Garlock 3000 gasket material combines flexible graphite with a stainless steel reinforcement to provide excellent sealing performance in demanding industrial applications. It is commonly used in flanges, valves and heat exchangers where long-term sealing reliability and resistance to high temperatures are required.
