Dimensions in this helper are derived from EN 1092-1 flange geometry where applicable.
If you are unsure, use Manual mode or contact us.
If you are unsure, use Manual mode or contact us.
Ring face is typically inside the bolts. Full face includes bolt holes.
Greyed-out DN/PN values are not advised for Silicone gaskets.
Use Manual mode, choose another material ore contact us if you require this configuration.
Use Manual mode, choose another material ore contact us if you require this configuration.
After applying, the values are copied into Manual mode and used for the drawing & RFQ.
Thickness depends on application, pressure, temperature and medium.
Any helper thickness is only a recommendation — contact us if you’re unsure.
Any helper thickness is only a recommendation — contact us if you’re unsure.
2D schematic
Live preview
Tip: enter PCD + hole Ø + holes to show bolt pattern.
Silicone gaskets specifications
Material type: Silicone rubber (VMQ)
Hardness: typically 40–70 Shore A
Temperature range: −60 °C to +200 °C (short-term up to +230 °C)
Elasticity: excellent
Sealing performance: reliable at low to medium pressures
Silicone rubber gaskets are widely used in applications where flexibility, temperature resistance and hygiene are important. They are suitable for food, pharmaceutical and general industrial sealing applications where chemical resistance requirements are moderate.
